- EVO Version: show version
- FA Chassis details: show chassis hardware detail
- Fan Speed: show chassis fan
- System Environment: show chassis environment no-forwarding
- Temperature Threshold: show chassis enhanced-temperature-thresholds
- AEC Optics Info: show picd optics fpc_slot 0 pic_slot 0 port 0 cmd info
- DR8 Optics Info : show picd optics fpc_slot 0 pic_slot 0 port 40 cmd info
- AEC Advertised Speed: show picd optics qsfpdd fpc_slot 0 pic_slot 0 port 0 cmd advertised_applications
- DR8 Advertised Speed: show picd optics qsfpdd fpc_slot 0 pic_slot 0 port 40 cmd advertised_applications
- Server NIC: lshw -c net -businfo
- LLDP Neighbor: show lldp neighbors
Commands for register read:
- To read the current values
- i2cset -y 1 0x9 0xfd 0x5; i2cget -y 1 0x9 0x72
- To reset the counter
- i2cset -y 1 0x9 0xfd 0x5; i2cset -y 1 0x9 0x72 0x0
- To read the values periodically or after the flap -
- i2cset -y 1 0x9 0xfd 0x5; i2cget -y 1 0x9 0x72
root@xai-qfx5240-01> show version
Hostname: xai-qfx5240-01
Model: qfx5240-64od
Junos: 23.4X100-D40.7-EVO
Yocto: 3.0.2
Linux Kernel: 5.2.60-yocto-standard-g72d147e
JUNOS-EVO OS 64-bit [junos-evo-install-qfx-ms-x86-64-23.4X100-D40.7-EVO]
## Credo AEC cable description (post D43 credo Y cables were recognized)
root@la-q5240-08:pfe> show picd optics qsfpdd fpc_slot 0 pic_slot 0 port 27 cmd advertised_applications
xcvr-0/0/27:
Ap Sel Host Intf Code Media Intf Code Host Lanes Media Lanes Host Assign Media Assign
1 100GAUI-1-S C2M (Annex 120G) (75) AOC (4) 1 1 255 255
2 100GAUI-1-L C2M (Annex 120G) (76) AOC (4) 1 1 255 255
3 200GAUI-2-S C2M (Annex 120G) (77) AOC (4) 2 2 85 85
4 200GAUI-2-L C2M (Annex 120G) (78) AOC (4) 2 2 85 85
5 400GAUI-4-S C2M (Annex 120G) (79) AOC (4) 4 4 17 17
6 400GAUI-4-L C2M (Annex 120G) (80) AOC (4) 4 4 17 17
root@xai-qfx5240-01> show chassis hardware detail
Hardware inventory:
Item Version Part number Serial number Description
Chassis AO40023030 QFX5240-64OD
PSM 0 6U6LX010130122W AC AFO 3000W PSU
PSM 1 6U6LX010130124P AC AFO 3000W PSU
Routing Engine 0 BUILTIN BUILTIN RE-QFX5240
nvme0 480103 MB EPM3750-M8480GB5 511240703133000269 NVMe Solid State Disk
nvme1 480103 MB EPM3750-M8480GB5 511240703133001074 NVMe Solid State Disk
CB 0 REV 03 650-175147 AO40023030 QFX5240-64OD
FPC 0 BUILTIN BUILTIN QFX5240-64OD
PIC 0 BUILTIN BUILTIN 64X800G-OSFP
Xcvr 0 XXXX NON-JNPR BL8J4455150007V UNKNOWN
Xcvr 1 XXXX NON-JNPR BL8J44551500031 UNKNOWN
Xcvr 2 XXXX NON-JNPR BL8J45X5150012J UNKNOWN
Xcvr 3 XXXX NON-JNPR BL8J4455150000B UNKNOWN
Xcvr 4 XXXX NON-JNPR BL8J435539000XH UNKNOWN
Xcvr 5 XXXX NON-JNPR BL8J435539001U4 UNKNOWN
Xcvr 6 XXXX NON-JNPR BL8J43X5440009W UNKNOWN
Xcvr 7 XXXX NON-JNPR BL8J43X544000BU UNKNOWN
Xcvr 8 XXXX NON-JNPR BL8J4355390012C UNKNOWN
Xcvr 9 XXXX NON-JNPR BL8J45X5150017N UNKNOWN
Xcvr 10 XXXX NON-JNPR BL8J44X515002M7 UNKNOWN
Xcvr 11 XXXX NON-JNPR BL8J435539001RL UNKNOWN
Xcvr 12 XXXX NON-JNPR BL8J45X5150000W UNKNOWN
Xcvr 13 XXXX NON-JNPR BL8J45X51500173 UNKNOWN
Xcvr 14 XXXX NON-JNPR BL8J4455150008U UNKNOWN
Xcvr 15 XXXX NON-JNPR BL8J45X515000TU UNKNOWN
Xcvr 16 XXXX NON-JNPR BL8J44X51500272 UNKNOWN
Xcvr 17 XXXX NON-JNPR BL8J44X51500254 UNKNOWN
Xcvr 18 XXXX NON-JNPR BL8J45X5150000F UNKNOWN
Xcvr 19 XXXX NON-JNPR BL8J43X544000L0 UNKNOWN
Xcvr 20 XXXX NON-JNPR BL8J44X5150028X UNKNOWN
Xcvr 21 XXXX NON-JNPR BL8J4455150002L UNKNOWN
Xcvr 22 XXXX NON-JNPR BL8J4455150004R UNKNOWN
Xcvr 23 XXXX NON-JNPR BL8J4455150001D UNKNOWN
Xcvr 24 XXXX NON-JNPR BL8J435515000F7 UNKNOWN
Xcvr 25 XXXX NON-JNPR BL8J4455150006E UNKNOWN
Xcvr 26 XXXX NON-JNPR BL8J4455150006G UNKNOWN
Xcvr 27 XXXX NON-JNPR BL8J4455150000G UNKNOWN
Xcvr 28 XXXX NON-JNPR BL8J43X544000GE UNKNOWN
Xcvr 29 XXXX NON-JNPR BL8J44551500061 UNKNOWN
Xcvr 30 XXXX NON-JNPR BL8J44X515002M4 UNKNOWN
Xcvr 31 XXXX NON-JNPR BL8J44X515001Y8 UNKNOWN
Xcvr 32 XXXX NON-JNPR BL8J435515000NZ UNKNOWN
Xcvr 33 XXXX NON-JNPR BL8J44X515001K6 UNKNOWN
Xcvr 34 XXXX NON-JNPR BL8J435539001K2 UNKNOWN
Xcvr 35 XXXX NON-JNPR BL8J435515000KY UNKNOWN
Xcvr 36 REV 01 740-174932 1G1TK1AA350HD OSFP-800G-DR8
Xcvr 37 REV 01 740-174933 1A1CVWA91100G OSFP-800G-DR8-P
Xcvr 38 REV 01 740-174933 1A1CVWA91102T OSFP-800G-DR8-P
Xcvr 39 REV 01 740-174933 1A1CVWA911007 OSFP-800G-DR8-P
Xcvr 40 REV 01 740-174932 1G1TK1AA350AZ OSFP-800G-DR8
Xcvr 41 REV 01 740-174933 1G1TVWA9361T9 OSFP-800G-DR8-P
Xcvr 42 REV 01 740-174933 1A1CVWA908009 OSFP-800G-DR8-P
Xcvr 43 REV 01 740-174933 1A1CVWA911037 OSFP-800G-DR8-P
Xcvr 44 REV 01 740-174933 1A1CVWA911018 OSFP-800G-DR8-P
Xcvr 45 REV 01 740-174933 1A1CVWA91101A OSFP-800G-DR8-P
Xcvr 46 REV 01 740-174933 1A1CVWA91104J OSFP-800G-DR8-P
Xcvr 47 REV 01 740-174933 1A1CVWA91101S OSFP-800G-DR8-P
Xcvr 48 REV 01 740-174933 1A1CVWA91100V OSFP-800G-DR8-P
Xcvr 49 REV 01 740-174933 1A1CVWA911014 OSFP-800G-DR8-P
Xcvr 50 REV 01 740-174933 1A1CVWA91104L OSFP-800G-DR8-P
Xcvr 51 REV 01 740-174933 1A1CVWA911015 OSFP-800G-DR8-P
Xcvr 52 REV 01 740-174932 1G1TK1AA3509S OSFP-800G-DR8
Xcvr 53 REV 01 740-174933 1A1CVWA90901N OSFP-800G-DR8-P
Xcvr 54 REV 01 740-174933 1A1CVWA911019 OSFP-800G-DR8-P
Xcvr 55 REV 01 740-174933 1A1CVWA91100W OSFP-800G-DR8-P
Xcvr 56 REV 01 740-174932 1G1TK1A94602E OSFP-800G-DR8
Xcvr 57 REV 01 740-174933 1A1CVWA91101V OSFP-800G-DR8-P
Xcvr 58 REV 01 740-174933 1A1CVWA9090C5 OSFP-800G-DR8-P
Xcvr 59 REV 01 740-174933 1A1CVWA91102L OSFP-800G-DR8-P
Xcvr 60 REV 01 740-174933 1A1CVWA911011 OSFP-800G-DR8-P
Xcvr 61 REV 01 740-174933 1A1CVWA9090C3 OSFP-800G-DR8-P
Xcvr 62 REV 01 740-174933 1A1CVWA91100R OSFP-800G-DR8-P
Fan Tray 0 QFX5240-64OD/QFX5240-64QD Fan Tray, Front to Back Airflow - AFO
Fan Tray 1 QFX5240-64OD/QFX5240-64QD Fan Tray, Front to Back Airflow - AFO
Fan Tray 2 QFX5240-64OD/QFX5240-64QD Fan Tray, Front to Back Airflow - AFO
Fan Tray 3 QFX5240-64OD/QFX5240-64QD Fan Tray, Front to Back Airflow - AFO
root@xai-qfx5240-01> show chassis environment no-forwarding
Class Item Status Measurement
Power PSM 0 OK 39 degrees C / 102 degrees F
PSM 1 OK 39 degrees C / 102 degrees F
Temp FPC 0 Sensor TH5 Max Reading OK 78 degrees C / 172 degrees F
FPC 0 xcvr-0/0/0 OK 50 degrees C / 122 degrees F
FPC 0 xcvr-0/0/1 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/2 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/3 OK 50 degrees C / 122 degrees F
FPC 0 xcvr-0/0/4 OK 53 degrees C / 127 degrees F
FPC 0 xcvr-0/0/5 OK 58 degrees C / 136 degrees F
FPC 0 xcvr-0/0/6 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/7 OK 52 degrees C / 125 degrees F
FPC 0 xcvr-0/0/8 OK 51 degrees C / 123 degrees F
FPC 0 xcvr-0/0/9 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/10 OK 58 degrees C / 136 degrees F
FPC 0 xcvr-0/0/11 OK 52 degrees C / 125 degrees F
FPC 0 xcvr-0/0/12 OK 52 degrees C / 125 degrees F
FPC 0 xcvr-0/0/13 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/14 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/15 OK 51 degrees C / 123 degrees F
FPC 0 xcvr-0/0/16 OK 53 degrees C / 127 degrees F
FPC 0 xcvr-0/0/17 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/18 OK 58 degrees C / 136 degrees F
FPC 0 xcvr-0/0/19 OK 54 degrees C / 129 degrees F
FPC 0 xcvr-0/0/20 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/21 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/22 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/23 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/24 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/25 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/26 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/27 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/28 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/29 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/30 OK 58 degrees C / 136 degrees F
FPC 0 xcvr-0/0/31 OK 54 degrees C / 129 degrees F
FPC 0 xcvr-0/0/32 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/33 OK 62 degrees C / 143 degrees F
FPC 0 xcvr-0/0/34 OK 61 degrees C / 141 degrees F
FPC 0 xcvr-0/0/35 OK 52 degrees C / 125 degrees F
FPC 0 xcvr-0/0/36 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/37 OK 64 degrees C / 147 degrees F
FPC 0 xcvr-0/0/38 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/39 OK 61 degrees C / 141 degrees F
FPC 0 xcvr-0/0/40 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/41 OK 61 degrees C / 141 degrees F
FPC 0 xcvr-0/0/42 OK 67 degrees C / 152 degrees F
FPC 0 xcvr-0/0/43 OK 62 degrees C / 143 degrees F
FPC 0 xcvr-0/0/44 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/45 OK 64 degrees C / 147 degrees F
FPC 0 xcvr-0/0/46 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/47 OK 63 degrees C / 145 degrees F
FPC 0 xcvr-0/0/48 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/49 OK 64 degrees C / 147 degrees F
FPC 0 xcvr-0/0/50 OK 67 degrees C / 152 degrees F
FPC 0 xcvr-0/0/51 OK 63 degrees C / 145 degrees F
FPC 0 xcvr-0/0/52 OK 58 degrees C / 136 degrees F
FPC 0 xcvr-0/0/53 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/54 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/55 OK 62 degrees C / 143 degrees F
FPC 0 xcvr-0/0/56 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/57 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/58 OK 61 degrees C / 141 degrees F
FPC 0 xcvr-0/0/59 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/60 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/61 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/62 OK 57 degrees C / 134 degrees F
FPC 0 MB Middle Right Rear OK 51 degrees C / 123 degrees F
FPC 0 MB Middle Left Rear OK 52 degrees C / 125 degrees F
FPC 0 MB Left Rear OK 45 degrees C / 113 degrees F
FPC 0 MB Left Front OK 44 degrees C / 111 degrees F
FPC 0 MB Right Rear OK 41 degrees C / 105 degrees F
FPC 0 MB Right Front OK 40 degrees C / 104 degrees F
FPC 0 MB OPTICS_GRP1_3V3 OK 51 degrees C / 123 degrees F
FPC 0 MB OPTICS_GRP2_3V3 OK 52 degrees C / 125 degrees F
FPC 0 MB OPTICS_GRP3_3V3 OK 51 degrees C / 123 degrees F
FPC 0 MB VDD_0P75 OK 63 degrees C / 145 degrees F
FPC 0 MB TRVDD1_0V9_0V75 OK 52 degrees C / 125 degrees F
FPC 0 MB TRVDD0_0V9_0V75 OK 53 degrees C / 127 degrees F
FPC 0 FB Exhaust Left OK 41 degrees C / 105 degrees F
FPC 0 FB Exhaust Right OK 41 degrees C / 105 degrees F
Routing Engine 0 CPU Temperature OK 75 degrees C / 167 degrees F
Routing Engine 0 Ch-0 DIMM-0 Temp OK 58 degrees C / 136 degrees F
Routing Engine 0 Ch-1 DIMM-0 Temp OK 60 degrees C / 140 degrees F
Fan Fan Tray 0 Fan 1 OK 12000 RPM
Fan Tray 0 Fan 2 OK 11850 RPM
Fan Tray 1 Fan 1 OK 12000 RPM
Fan Tray 1 Fan 2 OK 12000 RPM
Fan Tray 2 Fan 1 OK 12000 RPM
Fan Tray 2 Fan 2 OK 12000 RPM
Fan Tray 3 Fan 1 OK 12000 RPM
Fan Tray 3 Fan 2 OK 12000 RPM
root@xai-qfx5240-01> show chassis fan
Item Status % RPM Measurement
Fan Tray 0 Fan 1 OK 89% 12150 RPM
Fan Tray 0 Fan 2 OK 77% 12000 RPM
Fan Tray 1 Fan 1 OK 88% 12000 RPM
Fan Tray 1 Fan 2 OK 77% 12000 RPM
Fan Tray 2 Fan 1 OK 88% 12000 RPM
Fan Tray 2 Fan 2 OK 77% 12000 RPM
Fan Tray 3 Fan 1 OK 88% 12000 RPM
Fan Tray 3 Fan 2 OK 77% 12000 RPM
root@xai-qfx5240-01> show chassis environment no-forwarding
Class Item Status Measurement
Power PSM 0 OK 38 degrees C / 100 degrees F
PSM 1 OK 38 degrees C / 100 degrees F
Temp FPC 0 Sensor TH5 Max Reading OK 77 degrees C / 170 degrees F
FPC 0 xcvr-0/0/0 OK 50 degrees C / 122 degrees F
FPC 0 xcvr-0/0/1 OK 54 degrees C / 129 degrees F
FPC 0 xcvr-0/0/2 OK 54 degrees C / 129 degrees F
FPC 0 xcvr-0/0/3 OK 50 degrees C / 122 degrees F
FPC 0 xcvr-0/0/4 OK 53 degrees C / 127 degrees F
FPC 0 xcvr-0/0/5 OK 58 degrees C / 136 degrees F
FPC 0 xcvr-0/0/6 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/7 OK 51 degrees C / 123 degrees F
FPC 0 xcvr-0/0/8 OK 52 degrees C / 125 degrees F
FPC 0 xcvr-0/0/9 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/10 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/11 OK 52 degrees C / 125 degrees F
FPC 0 xcvr-0/0/12 OK 51 degrees C / 123 degrees F
FPC 0 xcvr-0/0/13 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/14 OK 58 degrees C / 136 degrees F
FPC 0 xcvr-0/0/15 OK 51 degrees C / 123 degrees F
FPC 0 xcvr-0/0/16 OK 52 degrees C / 125 degrees F
FPC 0 xcvr-0/0/17 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/18 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/19 OK 54 degrees C / 129 degrees F
FPC 0 xcvr-0/0/20 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/21 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/22 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/23 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/24 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/25 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/26 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/27 OK 54 degrees C / 129 degrees F
FPC 0 xcvr-0/0/28 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/29 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/30 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/31 OK 53 degrees C / 127 degrees F
FPC 0 xcvr-0/0/32 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/33 OK 62 degrees C / 143 degrees F
FPC 0 xcvr-0/0/34 OK 62 degrees C / 143 degrees F
FPC 0 xcvr-0/0/35 OK 52 degrees C / 125 degrees F
FPC 0 xcvr-0/0/36 OK 55 degrees C / 131 degrees F
FPC 0 xcvr-0/0/37 OK 64 degrees C / 147 degrees F
FPC 0 xcvr-0/0/38 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/39 OK 61 degrees C / 141 degrees F
FPC 0 xcvr-0/0/40 OK 57 degrees C / 134 degrees F
FPC 0 xcvr-0/0/41 OK 61 degrees C / 141 degrees F
FPC 0 xcvr-0/0/42 OK 67 degrees C / 152 degrees F
FPC 0 xcvr-0/0/43 OK 62 degrees C / 143 degrees F
FPC 0 xcvr-0/0/44 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/45 OK 64 degrees C / 147 degrees F
FPC 0 xcvr-0/0/46 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/47 OK 63 degrees C / 145 degrees F
FPC 0 xcvr-0/0/48 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/49 OK 64 degrees C / 147 degrees F
FPC 0 xcvr-0/0/50 OK 67 degrees C / 152 degrees F
FPC 0 xcvr-0/0/51 OK 63 degrees C / 145 degrees F
FPC 0 xcvr-0/0/52 OK 58 degrees C / 136 degrees F
FPC 0 xcvr-0/0/53 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/54 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/55 OK 62 degrees C / 143 degrees F
FPC 0 xcvr-0/0/56 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/57 OK 66 degrees C / 150 degrees F
FPC 0 xcvr-0/0/58 OK 61 degrees C / 141 degrees F
FPC 0 xcvr-0/0/59 OK 56 degrees C / 132 degrees F
FPC 0 xcvr-0/0/60 OK 60 degrees C / 140 degrees F
FPC 0 xcvr-0/0/61 OK 59 degrees C / 138 degrees F
FPC 0 xcvr-0/0/62 OK 57 degrees C / 134 degrees F
FPC 0 MB Middle Right Rear OK 51 degrees C / 123 degrees F
FPC 0 MB Middle Left Rear OK 51 degrees C / 123 degrees F
FPC 0 MB Left Rear OK 45 degrees C / 113 degrees F
FPC 0 MB Left Front OK 44 degrees C / 111 degrees F
FPC 0 MB Right Rear OK 41 degrees C / 105 degrees F
FPC 0 MB Right Front OK 40 degrees C / 104 degrees F
FPC 0 MB OPTICS_GRP1_3V3 OK 51 degrees C / 123 degrees F
FPC 0 MB OPTICS_GRP2_3V3 OK 52 degrees C / 125 degrees F
FPC 0 MB OPTICS_GRP3_3V3 OK 52 degrees C / 125 degrees F
FPC 0 MB VDD_0P75 OK 62 degrees C / 143 degrees F
FPC 0 MB TRVDD1_0V9_0V75 OK 52 degrees C / 125 degrees F
FPC 0 MB TRVDD0_0V9_0V75 OK 52 degrees C / 125 degrees F
FPC 0 FB Exhaust Left OK 41 degrees C / 105 degrees F
FPC 0 FB Exhaust Right OK 41 degrees C / 105 degrees F
Routing Engine 0 CPU Temperature OK 76 degrees C / 168 degrees F
Routing Engine 0 Ch-0 DIMM-0 Temp OK 57 degrees C / 134 degrees F
Routing Engine 0 Ch-1 DIMM-0 Temp OK 60 degrees C / 140 degrees F
Fan Fan Tray 0 Fan 1 OK 12000 RPM
Fan Tray 0 Fan 2 OK 12000 RPM
Fan Tray 1 Fan 1 OK 12000 RPM
Fan Tray 1 Fan 2 OK 12000 RPM
Fan Tray 2 Fan 1 OK 12000 RPM
Fan Tray 2 Fan 2 OK 12000 RPM
Fan Tray 3 Fan 1 OK 12000 RPM
Fan Tray 3 Fan 2 OK 12000 RPM
root@xai-qfx5240-01> show chassis enhanced-temperature-thresholds
Fan speed Fan speed Yellow alarm Red alarm Fire Shutdown
(degrees C) (degrees C) (degrees C) (degrees C) (degrees C)
Item Normal High Full Bad fan Normal Bad fan Normal Bad fan Normal
Routing Engine 0 CPU Temperature 75 85 99 96 101 98 103 100 105
Routing Engine 0 Ch-0 DIMM-0 Temp 63 70 80 77 82 79 85 82 88
Routing Engine 0 Ch-1 DIMM-0 Temp 63 70 80 77 82 79 85 82 88
FPC 0 Sensor TH5 Max Reading 75 80 95 92 100 97 105 102 110
FPC 0 xcvr-0/0/0 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/1 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/2 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/3 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/4 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/5 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/6 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/7 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/8 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/9 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/10 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/11 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/12 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/13 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/14 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/15 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/16 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/17 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/18 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/19 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/20 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/21 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/22 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/23 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/24 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/25 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/26 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/27 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/28 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/29 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/30 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/31 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/32 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/33 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/34 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/35 50 57 67 67 70 70 75 75 76
FPC 0 xcvr-0/0/36 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/37 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/38 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/39 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/40 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/41 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/42 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/43 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/44 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/45 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/46 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/47 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/48 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/49 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/50 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/51 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/52 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/53 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/54 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/55 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/56 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/57 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/58 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/59 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/60 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/61 53 60 70 70 73 73 76 76 77
FPC 0 xcvr-0/0/62 53 60 70 70 73 73 76 76 77
FPC 0 MB Middle Right Rear 45 50 75 72 80 77 85 82 90
FPC 0 MB Middle Left Rear 45 50 75 72 80 77 85 82 90
FPC 0 MB Left Rear 45 50 75 72 80 77 85 82 90
FPC 0 MB Left Front 45 50 75 72 80 77 85 82 90
FPC 0 MB Right Rear 45 50 75 72 80 77 85 82 90
FPC 0 MB Right Front 45 50 75 72 80 77 85 82 90
FPC 0 MB OPTICS_GRP1_3V3 75 80 110 107 115 112 120 117 125
FPC 0 MB OPTICS_GRP2_3V3 75 80 110 107 115 112 120 117 125
FPC 0 MB OPTICS_GRP3_3V3 75 80 110 107 115 112 120 117 125
FPC 0 MB VDD_0P75 75 80 110 107 115 112 120 117 125
FPC 0 MB TRVDD1_0V9_0V75 75 80 110 107 115 112 120 117 125
FPC 0 MB TRVDD0_0V9_0V75 75 80 110 107 115 112 120 117 125
FPC 0 FB Exhaust Left 40 45 60 57 65 62 70 67 75
FPC 0 FB Exhaust Right 40 45 60 57 65 62 70 67 75
root@xai-qfx5240-01:pfe> show picd optics fpc_slot 0 pic_slot 0 port 0 cmd info
PICD optics info
fpc_num: 0
pic_num: 0
port_num: 0
run_periodic: true
periodic_ticks: 7507
is_diagnostics: false
QSFP_presence: true
is_channelized: true
config_mismatch: false
Module firmware revision: 1.4
Module HW revision: 10.0
CMIS version: 0x50
Module State Machine: active_ready
DP State Machine
DP 0: dp_ready
DP 1: dp_ready
EEPROM details for XCVR: xcvr-0/0/0
QSFP-DD Lower Page:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x00:19 50 00 07 00 00 00 00 00 00 00 00 00 00 33 44
0x10:80 d4 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x20:00 00 00 00 00 00 00 01 04 00 00 00 00 00 00 00
0x30:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x40:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x50:00 00 00 00 00 04 4b 04 11 ff 4c 04 11 ff 4d 04
0x60:22 55 4e 04 22 55 4f 04 44 11 50 04 44 11 ff 00
0x70:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 11
QSFP-DD Upper Page 00h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:19 43 72 65 64 6f 20 20 20 20 20 20 20 20 20 20
0x90:20 9a ad ca 43 41 43 38 34 35 33 30 31 41 32 4e
0xa0:43 32 58 41 20 20 42 4c 38 4a 34 34 35 35 31 35
0xb0:30 30 30 37 56 20 32 35 30 34 30 39 20 20 20 20
0xc0:20 20 20 20 20 20 20 20 c0 34 2d 23 00 00 00 00
0xd0:00 00 00 03 0c 00 00 00 00 00 00 00 00 00 0e 00
0xe0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
QSFP-DD Upper Page 01h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:01 04 0a 00 00 00 00 00 00 00 00 00 00 00 20 00
0x90:59 60 46 00 00 02 9d 00 00 70 77 0b 03 06 06 03
0xa0:00 09 3d 67 0f 00 00 67 44 00 00 00 00 00 00 00
0xb0:ff ff 55 55 11 11 00 00 00 00 00 00 00 00 00 00
0xc0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xd0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xe0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 fd
QSFP-DD Upper Page 02h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:4b 00 fb 00 46 00 00 00 8b 42 76 8e 87 5a 7a 76
0x90:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xa0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xb0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xc0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xd0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xe0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 2e
Upper Page 10h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x90:00 50 50 50 50 58 58 58 58 ff 00 00 00 00 00 00
0xa0:ff ff 55 55 55 55 00 00 00 00 11 11 11 11 00 00
0xb0:00 00 00 00 10 12 14 16 18 1a 1c 1e ff 00 00 00
0xc0:00 00 00 ff ff 55 55 55 55 00 00 00 00 11 11 11
0xd0:11 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xe0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Upper Page 11h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:44 44 44 44 ff ff 00 00 00 00 00 00 00 00 00 00
0x90:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xa0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xb0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xc0:00 00 00 00 00 00 00 00 00 00 11 11 11 11 50 50
0xd0:50 50 58 58 58 58 ff 00 00 00 00 00 00 ff ff 55
0xe0:55 55 55 00 00 00 00 11 11 11 11 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Warning: Page 10h,11h maybe stale
Warning: Please run test picd optics cmd eeprom_rescan
root@xai-qfx5240-01:pfe> show picd optics qsfpdd fpc_slot 0 pic_slot 0 port 0 cmd advertised_applications
xcvr-0/0/0:
Ap Sel Host Intf Code Media Intf Code Host Lanes Media Lanes Host Assign Media Assign
1 100GAUI-1-S C2M (Annex 120G) (75) AOC with BER < 10^(-6) (4) 1 1 255 255
2 100GAUI-1-L C2M (Annex 120G) (76) AOC with BER < 10^(-6) (4) 1 1 255 255
3 200GAUI-2-S C2M (Annex 120G) (77) AOC with BER < 10^(-6) (4) 2 2 85 85
4 200GAUI-2-L C2M (Annex 120G) (78) AOC with BER < 10^(-6) (4) 2 2 85 85
5 400GAUI-4-S C2M (Annex 120G) (79) AOC with BER < 10^(-6) (4) 4 4 17 17
6 400GAUI-4-L C2M (Annex 120G) (80) AOC with BER < 10^(-6) (4) 4 4 17 17
root@xai-qfx5240-01:pfe> show picd optics qsfpdd fpc_slot 0 pic_slot 0 port 2 cmd advertised_applications
xcvr-0/0/2:
Ap Sel Host Intf Code Media Intf Code Host Lanes Media Lanes Host Assign Media Assign
1 100GAUI-1-S C2M (Annex 120G) (75) AOC with BER < 10^(-6) (4) 1 1 255 255
2 100GAUI-1-L C2M (Annex 120G) (76) AOC with BER < 10^(-6) (4) 1 1 255 255
3 200GAUI-2-S C2M (Annex 120G) (77) AOC with BER < 10^(-6) (4) 2 2 85 85
4 200GAUI-2-L C2M (Annex 120G) (78) AOC with BER < 10^(-6) (4) 2 2 85 85
5 400GAUI-4-S C2M (Annex 120G) (79) AOC with BER < 10^(-6) (4) 4 4 17 17
6 400GAUI-4-L C2M (Annex 120G) (80) AOC with BER < 10^(-6) (4) 4 4 17 17
root@xai-qfx5240-01:pfe> show picd optics qsfpdd fpc_slot 0 pic_slot 0 port 40 cmd advertised_applications
xcvr-0/0/40:
Ap Sel Host Intf Code Media Intf Code Host Lanes Media Lanes Host Assign Media Assign
1 400GAUI-4-S C2M (Annex 120G) (79) 400GBASE-DR4 (Clause 124) (28) 4 4 17 17
2 400GAUI-4-L C2M (Annex 120G) (80) 400GBASE-DR4 (Clause 124) (28) 4 4 17 17
3 100GAUI-1-S C2M (Annex 120G) (75) 100GBASE-DR (Clause 140) (20) 1 1 255 255
4 100GAUI-1-L C2M (Annex 120G) (76) 100GBASE-DR (Clause 140) (20) 1 1 255 255
5 800GAUI-8 S C2M (Annex 120G) (81) 800GBASE-DR8 (placeholder) (86) 8 8 1 1
6 800GAUI-8 L C2M (Annex 120G) (82) 800GBASE-DR8 (placeholder) (86) 8 8 1 1
7 200GAUI-2-S C2M (Annex 120G) (77) Vendor Specific/Custom (224) 2 2 85 85
8 200GAUI-2-L C2M (Annex 120G) (78) Vendor Specific/Custom (224) 2 2 85 85
root@xai-qfx5240-01:pfe> show picd optics fpc_slot 0 pic_slot 0 port 40 cmd info
PICD optics info
fpc_num: 0
pic_num: 0
port_num: 40
run_periodic: true
periodic_ticks: 6895
is_diagnostics: false
QSFP_presence: true
is_channelized: false
config_mismatch: false
Module firmware revision: 0.13
Module HW revision: 1.2
CMIS version: 0x51
Module State Machine: active_ready
DP State Machine
DP 0: dp_ready
EEPROM details for XCVR: xcvr-0/0/40
QSFP-DD Lower Page:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x00:19 51 00 07 00 00 00 00 00 00 00 00 00 00 39 ee
0x10:81 21 df fd 37 04 00 00 00 00 60 00 00 00 00 00
0x20:00 00 f0 00 ff 00 00 00 0d 00 00 00 00 00 00 00
0x30:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x40:00 00 00 01 00 00 d1 17 00 00 00 00 00 00 00 00
0x50:00 00 00 00 00 02 4f 1c 44 11 50 1c 44 11 4b 14
0x60:11 ff 4c 14 11 ff 51 56 88 01 52 56 88 01 4d e0
0x70:22 55 4e e0 22 55 00 00 00 00 00 00 00 00 00 00
QSFP-DD Upper Page 00h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:19 4a 55 4e 49 50 45 52 2d 31 47 31 20 20 20 20
0x90:20 20 1b c9 37 34 30 2d 31 37 34 39 33 32 20 20
0xa0:20 20 20 20 30 31 31 47 31 54 4b 31 41 41 33 35
0xb0:30 41 5a 20 20 20 32 35 30 38 32 36 20 20 43 4d
0xc0:55 49 41 5a 37 42 41 41 e0 42 00 28 00 00 00 00
0xd0:00 00 00 00 06 00 00 00 00 00 00 00 00 00 ec 31
0xe0:47 31 4b 31 41 20 20 20 20 20 20 20 20 20 20 30
0xf0:31 03 01 00 00 00 00 00 00 00 00 00 00 00 00 00
QSFP-DD Upper Page 01h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:00 00 01 02 05 00 00 00 00 00 66 6c 05 14 64 00
0x90:37 e9 46 00 00 00 9d 18 00 f0 77 bb 03 07 06 0f
0xa0:07 09 1d 77 ff 1f 80 47 34 00 00 00 00 00 00 00
0xb0:11 11 ff ff 01 01 55 55 55 55 00 00 00 00 00 00
0xc0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xd0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 4d
0xe0:00 22 55 4e 00 22 55 ff 00 00 00 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 6e
QSFP-DD Upper Page 02h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:4c 00 fa 00 49 00 fd 00 90 88 75 30 8c a0 77 24
0x90:7f ff 80 00 79 98 86 67 3c 00 2d 00 3a 00 2f 00
0xa0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xb0:9b 82 0a 0a 7b 86 0c a3 fd e8 13 88 f4 24 1d 4c
0xc0:ba f7 05 08 94 82 07 1b 00 00 00 00 00 00 00 00
0xd0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xe0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 b6
QSFP-DD Upper Page 03h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x90:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xa0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xb0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xc0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xd0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xe0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Upper Page 10h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x90:00 50 50 50 50 50 50 50 50 ff 00 00 00 00 00 00
0xa0:ff ff 22 22 22 22 00 00 00 00 11 11 11 11 00 00
0xb0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xc0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xd0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xe0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0xf0:00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Upper Page 11h:
0 1 2 3 4 5 6 7 8 9 a b c d e f
0x80:44 44 44 44 ff ff 00 00 00 00 00 00 00 00 00 00
0x90:00 00 00 00 00 00 00 00 00 00 4d 0b 3a 21 3b 9e
0xa0:35 21 45 38 2d c1 48 ff 3b c5 88 af 88 af 88 af
0xb0:88 af 88 af 88 af 88 af 88 af 42 32 42 85 52 1b
0xc0:42 de 40 a9 4b 4f 29 d3 3b 8f 11 11 11 11 50 50
0xd0:50 50 50 50 50 50 ff 00 00 00 00 00 00 ff ff 22
0xe0:22 22 22 00 00 00 00 11 11 11 11 00 00 00 00 00
0xf0:11 22 33 44 55 66 77 88 11 22 33 44 55 66 77 88
Warning: Page 10h,11h maybe stale
Warning: Please run test picd optics cmd eeprom_rescan
root@xai-qfx5240-01> show lldp neighbors
Local Interface Parent Interface Chassis Id Port info System Name
et-0/0/17:1 - 6c:92:cf:06:91:3e ens5f0np0 svl-hp-ai-srv01.englab.juniper.net
et-0/0/16:1 - 6c:92:cf:06:91:3e ens6f0np0 svl-hp-ai-srv01.englab.juniper.net
et-0/0/2:1 - 6c:92:cf:06:91:3e ens3f0np0 svl-hp-ai-srv01.englab.juniper.net
et-0/0/12:1 - 6c:92:cf:06:91:3e ens1f0np0 svl-hp-ai-srv01.englab.juniper.net
et-0/0/15:1 - 6c:92:cf:06:91:3e ens4f0np0 svl-hp-ai-srv01.englab.juniper.net
et-0/0/13:1 - 6c:92:cf:06:91:3e ens2f0np0 svl-hp-ai-srv01.englab.juniper.net
re0:mgmt-0 - 80:43:3f:1d:a7:80 ge-1/0/42 sd-mgmt-a25.englab.juniper.net
et-0/0/29:1 - ac:a0:9d:b3:0c:50 et-0/0/15 san-q5240-q09.englab.juniper.net
et-0/0/26:1 - ac:a0:9d:b3:0c:50 et-0/0/19 san-q5240-q09.englab.juniper.net
et-0/0/27:1 - ac:a0:9d:b3:0c:50 et-0/0/21 san-q5240-q09.englab.juniper.net
et-0/0/25:1 - ac:a0:9d:b3:0c:50 et-0/0/23 san-q5240-q09.englab.juniper.net
et-0/0/21:1 - ac:a0:9d:b3:0c:50 et-0/0/17 san-q5240-q09.englab.juniper.net
et-0/0/20:1 - ac:a0:9d:b3:0c:50 et-0/0/29 san-q5240-q09.englab.juniper.net
et-0/0/31:1 - ac:a0:9d:b3:0c:50 et-0/0/37 san-q5240-q09.englab.juniper.net
et-0/0/34:1 - ac:a0:9d:b3:0c:50 et-0/0/49 san-q5240-q09.englab.juniper.net
et-0/0/22:1 - ac:a0:9d:b3:0c:50 et-0/0/7 san-q5240-q09.englab.juniper.net
et-0/0/23:1 - ac:a0:9d:b3:0c:50 et-0/0/11 san-q5240-q09.englab.juniper.net
et-0/0/33:1 - b4:16:78:54:dc:4b et-0/0/42 san-q5240-q08.englab.juniper.net
et-0/0/30:0 - b4:16:78:54:dc:4b et-0/0/43 san-q5240-q08.englab.juniper.net
et-0/0/30:1 - b4:16:78:54:dc:4b et-0/0/44 san-q5240-q08.englab.juniper.net
et-0/0/24:0 - b4:16:78:54:dc:4b et-0/0/45 san-q5240-q08.englab.juniper.net
et-0/0/24:1 - b4:16:78:54:dc:4b et-0/0/46 san-q5240-q08.englab.juniper.net
et-0/0/53:0 - b4:16:78:54:dc:4b et-0/0/49 san-q5240-q08.englab.juniper.net
et-0/0/53:1 - b4:16:78:54:dc:4b et-0/0/50 san-q5240-q08.englab.juniper.net
et-0/0/58:0 - b4:16:78:54:dc:4b et-0/0/51 san-q5240-q08.englab.juniper.net
et-0/0/58:1 - b4:16:78:54:dc:4b et-0/0/52 san-q5240-q08.englab.juniper.net
et-0/0/42:0 - b4:16:78:54:dc:4b et-0/0/53 san-q5240-q08.englab.juniper.net
et-0/0/42:1 - b4:16:78:54:dc:4b et-0/0/54 san-q5240-q08.englab.juniper.net
et-0/0/32:0 - b4:16:78:54:dc:4b et-0/0/56 san-q5240-q08.englab.juniper.net
et-0/0/32:1 - b4:16:78:54:dc:4b et-0/0/57 san-q5240-q08.englab.juniper.net
et-0/0/28:0 - b4:16:78:54:dc:4b et-0/0/60 san-q5240-q08.englab.juniper.net
et-0/0/28:1 - b4:16:78:54:dc:4b et-0/0/61 san-q5240-q08.englab.juniper.net
et-0/0/19:0 - b4:16:78:54:dc:4b et-0/0/62 san-q5240-q08.englab.juniper.net
et-0/0/19:1 - b4:16:78:54:dc:4b et-0/0/63 san-q5240-q08.englab.juniper.net
et-0/0/44:0 - bc:0f:fe:09:ca:6e Connected to R0 Spine1 san-q5240-06.englab.juniper.net
et-0/0/44:1 - bc:0f:fe:09:ca:6e Connected to R0 Spine1 san-q5240-06.englab.juniper.net
et-0/0/51:0 - bc:0f:fe:09:ca:6e et-0/0/60:0 san-q5240-06.englab.juniper.net
et-0/0/51:1 - bc:0f:fe:09:ca:6e et-0/0/60:1 san-q5240-06.englab.juniper.net
et-0/0/57:0 - bc:0f:fe:09:ca:6e et-0/0/58:0 san-q5240-06.englab.juniper.net
et-0/0/57:1 - bc:0f:fe:09:ca:6e et-0/0/58:1 san-q5240-06.englab.juniper.net
et-0/0/55:1 - bc:0f:fe:09:ca:6e et-0/0/63:0 san-q5240-06.englab.juniper.net
et-0/0/55:0 - bc:0f:fe:09:ca:6e et-0/0/63:1 san-q5240-06.englab.juniper.net
et-0/0/61:0 - bc:0f:fe:09:ca:6e et-0/0/57:0 san-q5240-06.englab.juniper.net
et-0/0/61:1 - bc:0f:fe:09:ca:6e et-0/0/57:1 san-q5240-06.englab.juniper.net
et-0/0/60:0 - bc:0f:fe:09:ca:6e et-0/0/48:0 san-q5240-06.englab.juniper.net
et-0/0/41:0 - bc:0f:fe:09:ca:6e et-0/0/56:0 san-q5240-06.englab.juniper.net
et-0/0/41:1 - bc:0f:fe:09:ca:6e et-0/0/56:1 san-q5240-06.englab.juniper.net
et-0/0/39:0 - bc:0f:fe:09:ca:6e et-0/0/59:0 san-q5240-06.englab.juniper.net
et-0/0/39:1 - bc:0f:fe:09:ca:6e et-0/0/59:1 san-q5240-06.englab.juniper.net
et-0/0/60:1 - bc:0f:fe:09:ca:6e et-0/0/48:1 san-q5240-06.englab.juniper.net
et-0/0/56:0 - bc:0f:fe:09:ca:6e et-0/0/35:0 san-q5240-06.englab.juniper.net
et-0/0/56:1 - bc:0f:fe:09:ca:6e et-0/0/35:1 san-q5240-06.englab.juniper.net
et-0/0/50:0 - bc:0f:fe:09:ca:6e et-0/0/36:0 san-q5240-06.englab.juniper.net
et-0/0/50:1 - bc:0f:fe:09:ca:6e et-0/0/36:1 san-q5240-06.englab.juniper.net
et-0/0/40:0 - bc:0f:fe:09:ca:6e et-0/0/40:0 san-q5240-06.englab.juniper.net
et-0/0/40:1 - bc:0f:fe:09:ca:6e et-0/0/40:1 san-q5240-06.englab.juniper.net
et-0/0/36:0 - bc:0f:fe:09:ca:6e et-0/0/41:0 san-q5240-06.englab.juniper.net
et-0/0/36:1 - bc:0f:fe:09:ca:6e et-0/0/41:1 san-q5240-06.englab.juniper.net
et-0/0/62:0 - bc:0f:fe:09:ca:6e et-0/0/42:0 san-q5240-06.englab.juniper.net
et-0/0/62:1 - bc:0f:fe:09:ca:6e et-0/0/42:1 san-q5240-06.englab.juniper.net
et-0/0/37:0 - bc:0f:fe:09:ca:6e et-0/0/43:0 san-q5240-06.englab.juniper.net
et-0/0/37:1 - bc:0f:fe:09:ca:6e et-0/0/43:1 san-q5240-06.englab.juniper.net
et-0/0/52:0 - bc:0f:fe:09:ca:6e et-0/0/44:0 san-q5240-06.englab.juniper.net
et-0/0/52:1 - bc:0f:fe:09:ca:6e et-0/0/44:1 san-q5240-06.englab.juniper.net
et-0/0/54:0 - bc:0f:fe:09:ca:6e et-0/0/45:0 san-q5240-06.englab.juniper.net
et-0/0/54:1 - bc:0f:fe:09:ca:6e et-0/0/45:1 san-q5240-06.englab.juniper.net
et-0/0/45:1 - bc:0f:fe:09:ca:6e et-0/0/46:0 san-q5240-06.englab.juniper.net
et-0/0/45:0 - bc:0f:fe:09:ca:6e et-0/0/46:1 san-q5240-06.englab.juniper.net
et-0/0/38:0 - bc:0f:fe:09:ca:6e et-0/0/47:0 san-q5240-06.englab.juniper.net
et-0/0/38:1 - bc:0f:fe:09:ca:6e et-0/0/47:1 san-q5240-06.englab.juniper.net
et-0/0/46:1 - bc:0f:fe:09:ca:6e et-0/0/49:0 san-q5240-06.englab.juniper.net
et-0/0/46:0 - bc:0f:fe:09:ca:6e et-0/0/49:1 san-q5240-06.englab.juniper.net
et-0/0/48:1 - bc:0f:fe:09:ca:6e et-0/0/50:0 san-q5240-06.englab.juniper.net
et-0/0/48:0 - bc:0f:fe:09:ca:6e et-0/0/50:1 san-q5240-06.englab.juniper.net
et-0/0/43:1 - bc:0f:fe:09:ca:6e et-0/0/51:0 san-q5240-06.englab.juniper.net
et-0/0/43:0 - bc:0f:fe:09:ca:6e et-0/0/51:1 san-q5240-06.englab.juniper.net
et-0/0/49:0 - bc:0f:fe:09:ca:6e et-0/0/53:0 san-q5240-06.englab.juniper.net
et-0/0/49:1 - bc:0f:fe:09:ca:6e et-0/0/53:1 san-q5240-06.englab.juniper.net
et-0/0/47:1 - bc:0f:fe:09:ca:6e et-0/0/54:1 san-q5240-06.englab.juniper.net
et-0/0/59:0 - bc:0f:fe:09:ca:6e et-0/0/55:0 san-q5240-06.englab.juniper.net
et-0/0/59:1 - bc:0f:fe:09:ca:6e et-0/0/55:1 san-q5240-06.englab.juniper.net
et-0/0/10:1 - c4:cb:e1:d5:d5:a6 enp97s0f0np0 svl-d-ai-srv04
et-0/0/7:1 - c4:cb:e1:d5:d5:a6 enp202s0f0np0 svl-d-ai-srv04
et-0/0/11:1 - c4:cb:e1:d5:d5:a6 enp74s0f0np0 svl-d-ai-srv04
et-0/0/1:1 - c4:cb:e1:d5:d5:a6 enp13s0f0np0 svl-d-ai-srv04
et-0/0/0:1 - c4:cb:e1:d5:d5:a6 enp55s0f0np0 svl-d-ai-srv04
et-0/0/6:1 - c4:cb:e1:d5:d5:a6 enp225s0f0np0 svl-d-ai-srv04
et-0/0/14:1 - c4:cb:e1:d5:d5:a6 enp181s0f0np0 svl-d-ai-srv04
et-0/0/3:1 - c4:cb:e1:d5:d5:a6 enp160s0f0np0 svl-d-ai-srv04
et-0/0/0:0 - c4:cb:e1:d5:ed:a6 enp55s0f0np0 localhost
et-0/0/1:0 - c4:cb:e1:d5:ed:a6 enp13s0f0np0 localhost
et-0/0/3:0 - c4:cb:e1:d5:ed:a6 enp160s0f0np0 localhost
et-0/0/14:0 - c4:cb:e1:d5:ed:a6 enp181s0f0np0 localhost
et-0/0/6:0 - c4:cb:e1:d5:ed:a6 enp225s0f0np0 localhost
et-0/0/11:0 - c4:cb:e1:d5:ed:a6 enp74s0f0np0 localhost
et-0/0/10:0 - c4:cb:e1:d5:ed:a6 enp97s0f0np0 localhost
et-0/0/7:0 - c4:cb:e1:d5:ed:a6 enp202s0f0np0 localhost
et-0/0/18:0 - c4:cb:e1:f2:aa:0c enp180s0f0np0 san-rt-ai-srv01
et-0/0/5:0 - c4:cb:e1:f2:aa:0c enp73s0f0np0 san-rt-ai-srv01
et-0/0/9:0 - c4:cb:e1:f2:aa:0c enp201s0f0np0 san-rt-ai-srv01
et-0/0/4:0 - c4:cb:e1:f2:aa:0c enp225s0f0np0 san-rt-ai-srv01
et-0/0/18:1 - c4:cb:e1:f2:aa:14 enp13s0f0np0 san-rt-ai-srv02.englab.juniper.net
et-0/0/5:1 - c4:cb:e1:f2:aa:14 enp73s0f0np0 san-rt-ai-srv02.englab.juniper.net
et-0/0/4:1 - c4:cb:e1:f2:aa:14 enp225s0f0np0 san-rt-ai-srv02.englab.juniper.net
et-0/0/9:1 - c4:cb:e1:f2:aa:14 enp201s0f0np0 san-rt-ai-srv02.englab.juniper.net
et-0/0/8:1 - c4:cb:e1:f2:aa:14 enp97s0f0np0 san-rt-ai-srv02.englab.juniper.net
# Server info
root@svl-d-ai-srv04:~# lshw -c net -businfo
USB
Bus info Device Class Description
===========================================================
pci@0000:02:00.0 eno8303 network NetXtreme BCM5720 Gigabit Ethernet PCIe
pci@0000:02:00.1 eno8403 network NetXtreme BCM5720 Gigabit Ethernet PCIe
pci@0000:0d:00.0 enp13s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:22:00.0 eno12399np0 network BCM57414 NetXtreme-E 10Gb/25Gb RDMA Ethernet Controller
pci@0000:22:00.1 eno12409np1 network BCM57414 NetXtreme-E 10Gb/25Gb RDMA Ethernet Controller
pci@0000:37:00.0 enp55s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:4a:00.0 enp74s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:61:00.0 enp97s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:a0:00.0 enp160s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:b5:00.0 enp181s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:ca:00.0 enp202s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:e1:00.0 enp225s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
root@svl-d-ai-srv03:~# lshw -c net -businfo
Bus info Device Class Description
===========================================================
pci@0000:02:00.0 eno8303 network NetXtreme BCM5720 Gigabit Ethernet PCIe
pci@0000:02:00.1 eno8403 network NetXtreme BCM5720 Gigabit Ethernet PCIe
pci@0000:0d:00.0 enp13s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:22:00.0 eno12399np0 network BCM57414 NetXtreme-E 10Gb/25Gb RDMA Ethernet Controller
pci@0000:22:00.1 eno12409np1 network BCM57414 NetXtreme-E 10Gb/25Gb RDMA Ethernet Controller
pci@0000:37:00.0 enp55s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:4a:00.0 enp74s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:61:00.0 enp97s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:a0:00.0 enp160s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:b5:00.0 enp181s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:ca:00.0 enp202s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:e1:00.0 enp225s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
root@san-rt-ai-srv01:~# lshw -c net -businfo
Bus info Device Class Description
============================================================
pci@0000:02:00.0 eno8303 network NetXtreme BCM5720 Gigabit Ethernet PCIe
pci@0000:02:00.1 eno8403 network NetXtreme BCM5720 Gigabit Ethernet PCIe
pci@0000:0d:00.0 enp13s0np0 network MT2910 Family [ConnectX-7]
pci@0000:3a:00.0 enp58s0 network DSC Ethernet Controller
pci@0000:49:00.0 enp73s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:9f:00.0 network Broadcom Inc. and subsidiaries
pci@0000:b4:00.0 enp180s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:c9:00.0 enp201s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:e1:00.0 enp225s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
usb@1:10.3 idrac network Ethernet interface
root@san-rt-ai-srv02:~# lshw -c net -businfo
Bus info Device Class Description
============================================================
pci@0000:02:00.0 eno8303 network NetXtreme BCM5720 Gigabit Ethernet PCIe
pci@0000:02:00.1 eno8403 network NetXtreme BCM5720 Gigabit Ethernet PCIe
pci@0000:0d:00.0 enp13s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:37:00.0 enp55s0np0 network MT2910 Family [ConnectX-7]
pci@0000:49:00.0 enp73s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:61:00.0 enp97s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:9f:00.0 network Broadcom Inc. and subsidiaries
pci@0000:b4:00.0 enp180s0np0 network MT2910 Family [ConnectX-7]
pci@0000:c9:00.0 enp201s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:e1:00.0 enp225s0f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
root@svl-hp-ai-srv01:~# lshw -c net -businfo
Bus info Device Class Description
============================================================
pci@0000:12:00.0 ens3f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:26:00.0 ens2f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:3a:00.0 ens14f0 network NetXtreme BCM5719 Gigabit Ethernet PCIe
pci@0000:3a:00.1 ens14f1 network NetXtreme BCM5719 Gigabit Ethernet PCIe
pci@0000:3a:00.2 ens14f2 network NetXtreme BCM5719 Gigabit Ethernet PCIe
pci@0000:3a:00.3 ens14f3 network NetXtreme BCM5719 Gigabit Ethernet PCIe
pci@0000:62:00.0 ens1f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:8a:00.0 ens5f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:9f:00.0 ens6f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
pci@0000:c9:00.0 ens4f0np0 network MT43244 BlueField-3 integrated ConnectX-7 network controller
Commands for register read:
vrf:none] root@svla-q5240-q02:~# i2cset -y 1 0x9 0xfd 0x5; i2cget -y 1 0x9 0x72
0x00
[vrf:none] root@svla-q5240-q02:~# i2cset -y 1 0x9 0xfd 0x5; i2cset -y 1 0x9 0x72 0x0
[vrf:none] root@svla-q5240-q02:~# i2cset -y 1 0x9 0xfd 0x5; i2cget -y 1 0x9 0x72
0x00
